5.0L GEN 3 ALUMINATOR SC SHORT BLOCK 9.5:1

5.0L GEN 3 ALUMINATOR SC SHORT BLOCK 9.5:1
5.0L GEN 3 ALUMINATOR SC SHORT BLOCK 9.5:1
5.0L GEN 3 ALUMINATOR SC SHORT BLOCK 9.5:1
5.0L GEN 3 ALUMINATOR SC SHORT BLOCK 9.5:1
5.0L GEN 3 ALUMINATOR SC SHORT BLOCK 9.5:1
5.0L GEN 3 ALUMINATOR SC SHORT BLOCK 9.5:1
5.0L GEN 3 ALUMINATOR SC SHORT BLOCK 9.5:1
M-6009-A50SCB
Retail
$7,150.00
Sold in Units of
Each (1)
Instruction Sheet
Available (PDF)
Sign in to add to wish list
WARNING:
This part is designed and intended for competition use only or off-highway use only. It should not be installed on a vehicle that is driven on public roads and highways. Installation of this part on a vehicle driven on public roads and highways is likely to violate U.S. and Canadian laws and regulations relating to motor vehicle emissions.
Proudly Made in the USA
Just like the fully built-up engines, Aluminator Short Blocks are hand assembled and use Manley® connecting rods with ARP® rod bolts and Mahle® forged pistons.  Two versions are available – 9.5: and 12.0:1 compression ratio.

These Aluminator Short Blocks serve as a strong foundation for the enthusiast that wants to spec and finish a Coyote build to his or her particular application and needs.

Ford Performance Engineers have taken care of the toughest part of building a new engine by designing a strong and durable Short Block that offers a wide range of power possibilities.  And every Ford Performance Aluminator Short Block is precision internally balanced and hand assembled in the U.S. with performance clearances.

Ford Performance offers a number of components to finish the build.

Specs: Aluminator Short Block M-6009-A50SCB

  • 5.0L - 302 cubic inches
  • 9.5:1 compression ratio (nominal)
  • For 12.0:1 compression ratio version see M-6009-A50NAB
  • Mahle® hard anodized forged pistons with Grafal® low friction coating
  • Manley® H-beam connecting rods with ARP® 2000 bolts
  • 2018+ (Gen 3) Production aluminum cylinder block features cross-bolted main bearing caps and thick main bearing bulkheads for bottom-end strength
  • Forged steel crankshaft
  • Accepts Gen 1, 2, 3, 4 or GT350 cylinder heads with corresponding generation head gasket
  • Assembled and ready for your heads, cam, timing set, and oil system
  • Oil pump, pickup and oil pan not included
  • M-6675-M52 oil pan/pump or M-6675-M52S oil pan/pump recommended
  • Fully compatible with 2024+ Mustang 5.0L oil pan/pump/pick-up

Photo and specs may vary

Part Type
Engine: Short Blocks
Instruction Sheet
Warranty Availability
Not Available
Package Dimensions
25" x 24" x 31"
Package Weight
360 lb(s)
UPC Code
756122014264
Country of Origin
United States
